性能特點
Main Feature
1. 不需要預先工序，如折彎間隔條，涂抹丁基膠，貼鋁框組裝等
2. 雙鼓泵供料系統可連續(xù)供應和排出TPI液體
3. 可同時加工金屬(鋁)間隔條和TPI間隔條
1. No need for pre-process, such as bending spacers, applying butyl glue on spacer, and assembling aluminum spacer frame.
2. The dual drum pump feeding system can continuously supply and discharge TPI liquid.
3. Can simultaneously process metal (aluminum) spacer bars and TPI spacer bars.
主要技術參數（Main Techniq ue Parameter） | |||||||||
產品型號 Product model | 最大玻璃尺寸mm Max.glass size | 最小加工尺寸 Min.Glass Size | 功率 Power supply | 加料噴嘴 Feeding nozzle | 傳送速度 Transmission speed | 供應系統 Supply system | 供料系統 Feeding system | 加料速度 Feeding speed | 吸力類型 Suction type |
WLTPSS2000 | 2000×3000 | 300×400 | 122.6kW | 6.8/5.8 | 40m/min | 雙泵Dual pump | 加熱軟管heating hose | 20m/min | 帶/墊 Belt/pad |
WLTPSS2500 | 2500×3600 | 300×400 | 126kW | 6.8/5.8 | 40m/min | 雙泵Dual pump | 加熱軟管heating hose | 20m/min | 帶/墊 Belt/pad |
